농축기/엑기스 생산라인

제품사양

농축기ENRICHING UNIT

1. 내용액 연속 공급The Solution Will be Supplied Continously.

2. 스팀사용 압력 : 0.8kg/㎠ Manintain the Steam Pressure Within 0.8kg/㎠

3. 진공 : 600~700mmHgVaccum : 600~700mmHg

4. 농축시간 : 냉각수 온도에 따라 시간 변화 있음.The enriching hours will differ according to the temperature of cooling water.

추출기EXTRACTING UNIT

1. 상부 맨홀 원료 투입Input the material through the upper manhole.

2. 스팀사용 압력 : 1kg/㎠Manintain the Steam Pressure Within 1kg/㎠

3. 추출시간 : 4시간 이내Extracting hours will be within 4 hours.

4. 추출액 : 저장탱크 이송Extrated solution to the storing tank.

5. 하부 맨홀 약재 토출Medicine solution comes down through the lower manhole.

여과기FILTER UNIT

1. 추출 원액을 저장탱크로 옮길 때 펌프가압 - 1차 여과The extracted solution will be first filtered by pumping pressure when passing from the extracter to tank.

2. 저장탱크에서 농축기로 옮길 때 가압 - 2차 여과The first filtered solution will be refiltered when passing from the tack to the enriching unit.

3. 여과포를 2개씩 제작 교체 사용The two pieces of filtering cloth can be replaced by turns.

저장탱크STORING UNIT

1. 추출 원액을 농출 전에 저장Store the extracted solution before enriched.

2. 스팀사용 압력 : 0.5kg/㎠Manintain the Steam Pressure Within 0.5kg/㎠

3. 사용온도 : 60℃~70℃Keep the temperature between 60℃~70℃

4. 가열원리 : 원액 변질 방지Heating prevents the solution from spoiling.
